High-Efficiency YAG & Diode Hybrid Laser Welder with Optimized Energy Distribution

  • 1
  • 2

Brand Name : HanWei

Model Number : HW-YD-600-1000/1500/ 2000W

Certification : CE

Place of Origin : Shenzhen, China

MOQ : 1 Set

Price : USD / Set

Payment Terms : T/T

Supply Ability : 2000 Sets / year

Delivery Time : 10 working days

Packaging Details : Export Plywood Packing

Model : HW-YD-600-1000/HW-YD-600-1500/HW-YD-600-2000

Wavelength : 915nm + 1064nm

Power Stability : ± 0.5 %

Output Power : 1600 W/2000 W/2600 W

Cooling mode : Water Cooling

Pulse Width : 0.5 - CW

Fiber core(um) : 400+50 um

Laser Power : YAG laser 600 W Fiber laser 1000W/YAG laser 600 W Fiber laser 1500W/YAG laser 600 W Fiber laser 2000W

Contact Now

High-Efficiency YAG & Diode Hybrid Laser Welder with Optimized Energy Distribution
The YAG & semiconductor hybrid welding machine uses semiconductor laser to perform thermal modulation on the material surface before welding, bringing the workpiece into a state more suitable for laser interaction and thus enhancing the absorption of laser energy. Subsequently, the fiber laser acts on the welding area with high power density, rapidly establishing a deep penetration channel and maintaining a stable keyhole, achieving efficient energy coupling and a continuous welding process.
High-Efficiency YAG & Diode Hybrid Laser Welder with Optimized Energy Distribution
Technical Specifications
Model HW-YD-600-1000 HW-YD-600-1500 HW-YD-600-2000
Laser Power YAG laser 600 W
Fiber laser 1000W		 YAG laser 600 W
Fiber laser 1500W		 YAG laser 600 W
Fiber laser 2000W
Wavelength 915nm + 1064nm 915nm + 1064nm 915nm + 1064nm
Power stability ± 0.5 % ± 0.5 % ± 0.5 %
Output Power 1600 W 2000 W 2600 W
Cooling method Water Cooling Water Cooling Water Cooling
Fiber core (um) 400+50 um 400+50 um 400+50 um
Pulse width 0.5 - CW 0.5 - CW 0.5 - CW
Product Features

  • Synergistic Mechanism of Preheating Modulation and Deep Penetration Formation

  • Improved Stability in Aluminum Alloy Welding

  • Excellent Weld Performance and Consistency

  • Meeting the Welding Requirements of Power Battery Seal Pins

  • Optimized Energy Distribution for Enhanced Processing Efficiency


Application Advantages
Through the participation of hybrid lasers in the welding process, rational energy distribution is realized, so that a single laser source does not need to undertake the entire welding task. While ensuring welding depth and strength, the welding speed is significantly increased and processing time is reduced, providing higher efficiency for automated production lines.
This hybrid welding equipment is particularly suitable for the seal pin connection process in power batteries, enabling stable welding at high speeds. The equipment ensures firm and reliable welding of the seal pin area, providing a high-quality welding solution for new energy battery manufacturing and meeting the efficiency and quality requirements of modern battery production lines.
About Shenzhen Hanwei Laser
Shenzhen Hanwei Laser is committed to popularizing world-class laser welding technologies among system integrators of all types. As a dual-certified organization accredited as both a national high-tech enterprise and a "specialized, sophisticated, distinctive, and innovative" enterprise, we focus on the full-industry-chain research and development, production, and distribution of welding-specific lasers as well as their matching technical solutions.

Our comprehensive product portfolio includes mold repair laser welding systems, QCW laser welding equipment, YAG and diode laser welding apparatuses, hybrid welding systems (covering blue laser + fiber, diode + fiber, and YAG + diode configurations), blue laser welding devices, and ring-spot laser welding systems.

For aluminum and aluminum alloy welding scenarios, our hybrid lasers support simultaneous beam emission, facilitating flawless synchronization between preheating and deep penetration procedures. This function effectively resolves common issues such as porosity and spattering in aluminum welding; by enhancing the flow stability of the molten pool at high processing speeds, it guarantees the formation of uniform and continuous weld seams, reduces defect rates, and improves processing consistency—rendering it highly suitable for welding high-precision aluminum structural components.
High-Efficiency YAG & Diode Hybrid Laser Welder with Optimized Energy Distribution
High-Efficiency YAG & Diode Hybrid Laser Welder with Optimized Energy Distribution
High-Efficiency YAG & Diode Hybrid Laser Welder with Optimized Energy Distribution
High-Efficiency YAG & Diode Hybrid Laser Welder with Optimized Energy Distribution
